555 计时器,IntersilIntersil 提供 555 计时器,这是一款高度稳定的控制器,能够产生精确的定时脉冲。 具有单稳态操作,您可通过一个外部电阻器和一个电容器控制延时。 具有稳定操作,使用两个外部电阻器和一个电容器精确控制频率和负载循环。从微秒至天定时 ICM7242 是远程固定计时器 ### 定时器/定时发生器
The is a CMOS RC timer providing significantly improved performance over the standard SE/NE555/6 and 355 timers, while at the same time being a direct replacement for those devices in most applications. For a stable operation as an oscillator, the free running frequency and the duty cycle are both accurately controlled by two external resistors and one capacitor. The circuit is triggered and reset on falling negative waveforms, and the output inverter can source or sink currents large enough to drive TTL loads, or provide minimal offsets to drive CMOS loads.
频率 1 MHz
电源电压DC 2.00V min
额定电流 60.0 A
输出接口数 1
供电电流 60 µA
针脚数 8
工作温度Max 85 ℃
工作温度Min -25 ℃
电源电压 2V ~ 18V
电源电压Max 18 V
电源电压Min 2 V
安装方式 Through Hole
引脚数 8
封装 DIP-8
长度 10.16 mm
宽度 7.11 mm
高度 4.95 mm
封装 DIP-8
工作温度 -25℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
制造应用 Clock & Timing, 时钟与计时
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ICM7555IPAZ Intersil 英特矽尔 | 当前型号 | 当前型号 |
ICM7555IPA 英特矽尔 | 类似代替 | ICM7555IPAZ和ICM7555IPA的区别 |
TLC555CP 德州仪器 | 功能相似 | ICM7555IPAZ和TLC555CP的区别 |
TLC555IP 德州仪器 | 功能相似 | ICM7555IPAZ和TLC555IP的区别 |
