Intersil### 隔离电源,Intersil
The is a CMOS Voltage Converter. The ICL7660A monolithic CMOS power supply circuits which offer unique performance advantages over previously available devices. The ICL7660 performs supply voltage conversions from positive to negative for an input range of +1.5 to +10.0V resulting in complementary output voltages of -1.5 to -10.0V and the ICL7660A does the same conversions with an input range of +1.5 to +12.0V resulting in complementary output voltages of -1.5 to -12.0V. Only 2 noncritical external capacitors are needed for the charge pump and charge reservoir functions. The ICL7660A can also be connected to function as voltage doublers and will generate output voltages up to +18.6V with a +10V input.
ESD sensitive device, take proper precaution while handling the device.
频率 10.0 kHz
电源电压DC 1.50V min
输出接口数 1
输出电压 -12.0 V min
输出电流 45 mA
供电电流 0.16 mA
针脚数 8
开关频率 3 kHz
输入电压Max 12 V
输入电压Min 1.5 V
工作温度Max 70 ℃
工作温度Min 0 ℃
输入电压 1.5.12 V
安装方式 Through Hole
引脚数 8
封装 DIP-8
长度 10.16 mm
宽度 7.11 mm
高度 4.95 mm
封装 DIP-8
工作温度 0℃ ~ 70℃ TA
产品生命周期 Active
包装方式 Tube
制造应用 Power Management, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ICL7660ACPAZ Intersil 英特矽尔 | 当前型号 | 当前型号 |
ICL7660ACPA 英特矽尔 | 完全替代 | ICL7660ACPAZ和ICL7660ACPA的区别 |
TC7662AEPA 微芯 | 功能相似 | ICL7660ACPAZ和TC7662AEPA的区别 |
TC7660CPA 微芯 | 功能相似 | ICL7660ACPAZ和TC7660CPA的区别 |
