ISL6264CRZ

两相核心控制器的AMD移动炫龙处理器 Two-Phase Core Controller for AMD Mobile Turion CPUs

The ISL6264 is a two-phase buck converter regulator with embedded gate drivers. The two-phase buck converter uses two interleaved channels to effectively double the output voltage ripple frequency and thereby reduce output voltage ripple amplitude with fewer components, lower component cost, reduced power dissipation, and smaller real estate area. ISL6264 can also be configured as single-phase controller for low power CPU applications.

Features

• Precision Two-phase Core Voltage Regulator

\- 0.5% system accuracy over temperature

• Voltage positioning with Adjustable Load Line and Offset

• Internal Gate Driver with 2A Driving Capability

• Dynamic Phase Adding/Dropping

• Differential Current Sensing: DCR or resistor

• Microprocessor Voltage Identification Input

\- 6-Bit VID Input

\- 0.775V to 1.55V in 12.5mV Steps

\- 0.375V to 0.7625V in 25mV Steps

• Adjustable Reference-Voltage Offset

• Audio Filter Enable/Disable

• User Programmable Switching Frequency

• Differential Remote CPU Die Voltage Sensing

• Static and Dynamic Current Sharing

• Overvoltage, Undervoltage, and Overcurrent Protection
