ISO122UE4

TEXAS INSTRUMENTS  ISO122UE4  隔离放大器, 精准, 1个放大器, 50 mV, 1.5 kV, ± 4.5V 至 ± 18V, SOIC, 8 引脚

The is a Precision Isolation Amplifier incorporates a novel duty cycle modulation-demodulation technique. The signal is transmitted digitally across a 2pF differential capacitive barrier. With digital modulation the barrier characteristics do not affect signal integrity, thus resulting in excellent reliability and good high-frequency transient immunity across the barrier. The ISO122 is easy to use. No external components are required for operation. The key specifications are 0.020% maximum nonlinearity, 50kHz signal bandwidth and 200V/°C VOS drift. A power supply range of 4.5V to 18V and quiescent currents of 5mA on VS1 and ±5.5mA on VS2 make the amplifier ideal for a wide range of applications.

.

100% Tested for high-voltage breakdown

.

Ease of use, fixed unity gain Configuration

.

Green product and no Sb/Br

This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
