C & K COMPONENTS ITS50FV1ST 轻触开关, 不发光, 160 gf, 12 V, 50 mA, 通孔
The is an illuminated through-hole Tactile Switch features NO momentary action and white LED. It has silver-plated brass terminals.
得捷:
SWITCH TACTILE SPST-NO 0.05A 12V
立创商城:
ITS50FV1ST
e络盟:
C & K COMPONENTS ITS50FV1ST 轻触开关, 不发光, 160 gf, 12 V, 50 mA, 通孔
艾睿:
The ITS50FV1ST tactile switch from C&a;K Components lets you quickly turn on your system by use of pressure. This device has a maximum current rating of 0.05 A @ 12VDC. It has a SPST configuration. This tactile switch has an operating temperature range of -25 °C to 70 °C. The ITS50FV1ST tactile switch has a PC pin termination style. This product is 7.2 mm long, 7.15 mm tall and 7.2 mm deep. The maximum DC voltage rating is 12 VDC. This button actuator is 2.5 mm long.
安富利:
Switch Tactile N.O. SPST Button PC Pins 0.05A 12VDC 50000Cycle 1.57N Thru-Hole Tray
Verical:
Switch Tactile N.O. SPST Button PC Pins 0.05A 12VDC 50000Cycles 1.57N Thru-Hole Tray
额定电压DC 12 V
排数 2
额定电流Max 0.05A @12VDC
工作温度Max 70 ℃
工作温度Min -25 ℃
额定电压DC Max 12 V
接触电阻Max <100 mΩ
安装方式 Through Hole
引脚数 4
封装 -
长度 7.2 mm
宽度 7.2 mm
高度 7.15 mm
封装 -
颜色 Black
触点材质 Brass
工作温度 -25℃ ~ 70℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
