VISHAY IHLP5050EZER100M01 表面贴装功率电感器, IHLP-5050EZ-01系列, 10 µH, ± 20%, 屏蔽, 0.0255 ohm, 9 A
* Shielded construction * Frequency range up to 5.0 MHz * Lowest DCR/μH, in this package size * Handles high transient current spikes without saturation * Ultra low buzz noise, due to composite construction * Compliant to RoHS Directive 2002/95/EC
欧时:
### IHLP5050EZ-01 Series Magnetically Shielded Wire Wound ChokesVishay IHLP-5050EZ-01 series high current low profile shielded inductors. The IHLP-5050EZ-01 series handles high transient current spikes without saturation and has ultra low buzz noise due to its composite construction. Frequency range up to 5.0 MHz Lowest DC Resistance / μH in this package size Applications include: PDA/notebook/desktop/server devices; High current POL converters; Low profile, high current power supplies; Battery powered devices; DC/DC converters in distributed power systems; DC/DC converter for Field Programmable Gate Array FPGA ### Vishay 非标准表面安装电感器(扼流圈)
艾睿:
Inductor Power Shielded Wirewound 10uH 20% 100KHz 9A 25.5mOhm DCR 5050 T/R
安富利:
Ind High Current Shielded Wirewound 10uH 20% 100KHz 9A 5050 T/R
Verical:
Inductor Power Shielded Wirewound 10uH 20% 100KHz 9A 25.5mOhm DCR 5050 T/R
Newark:
# VISHAY IHLP5050EZER100M01 Surface Mount Power Inductor, IHLP-5050EZ-01 Series, 10 µH, 9 A, 16 A, Shielded, 0.0255 ohm
儒卓力:
**IHLP5050EZ 10,0uH 9,0A 20% **
额定电流 9.00 A
容差 ±20 %
电感 10 µH
自谐频率 100 kHz
电阻 21.4 mΩ
共振频率 100 kHz
屏蔽 Yes
电感公差 ±20 %
测试频率 100 KHz
工作温度Max 125 ℃
工作温度Min -55 ℃
电阻DC Max 0.0255 Ω
安装方式 Surface Mount
引脚数 2
封装 13.2mm x 12.9mm x 5mm
长度 13.2 mm
宽度 12.9 mm
高度 5 mm
封装 13.2mm x 12.9mm x 5mm
工作温度 -55℃ ~ 125℃
包装方式 Cut Tape CT
制造应用 Computers & Computer Peripherals, Industrial, Consumer Electronics, Communications & Networking, Power Management
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
IHLP5050EZER100M01 Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
SRP1250-100M 伯恩斯 | 功能相似 | IHLP5050EZER100M01和SRP1250-100M的区别 |
ETQP5M100YFC 松下 | 功能相似 | IHLP5050EZER100M01和ETQP5M100YFC的区别 |
