TEXAS INSTRUMENTS ISO7140FCCDBQ 芯片, 数字式隔离器, 4通道, 50MBPS, SSOP-16
The is a quad-channel Digital Isolator provides galvanic isolation up to 2500VRMS for 1 minute per UL and 4242VPK per VDE. It has three channels with two forward and one reverse-direction channels. It is capable of 50Mbps maximum data rate with 5V supplies and 40Mbps maximum data rate with 3.3 or 2.7V supplies, with integrated filters on the inputs for noise-prone applications. Each isolation channel has a logic input and output buffer separated by a silicon dioxide SiO2 insulation barrier. Used with isolated power supplies, these devices prevent noise currents on a data bus or other circuits from entering the local ground and interfering with or damaging sensitive circuitry.
Device has limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
电源电压DC 2.70 V, 3.30 V, 5.00 V
上升/下降时间 2 ns
通道数 4
针脚数 16
耗散功率 150 mW
数据速率 50.0 Mbps
隔离电压 2500 Vrms
过温保护 No
下降时间Max 3 ns
上升时间Max 3 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 150 mW
电源电压 2.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 16
封装 SSOP-16
封装 SSOP-16
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Each
制造应用 工业, 通信与网络
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ISO7140FCCDBQ TI 德州仪器 | 当前型号 | 当前型号 |
ISO7140FCCDBQR 德州仪器 | 完全替代 | ISO7140FCCDBQ和ISO7140FCCDBQR的区别 |
