按钮开关 Momentary pushbutton NO/PLNGR RED
The IP series pushbutton switch is offered with momentary and latching push on - push off configurations, and is available with illumination. Expected life of 200,000 cycles. Manufactured with gold plated silver contacts and with solder lug terminals or insulated wire leads.
立创商城:
IPR3FAD6
贸泽:
按钮开关 Momentary pushbutton NO/PLNGR RED
Allied Electronics:
Switch; P/B; Sealed; SPST-NO; OFF-MOM; Non-Illum; Rnd; Red Actuator; 0.5A; 48VAC/DC; Wire
Chip1Stop:
Switch Push Button N.O. SPST Round Plunger 5A 48VAC 48VDC Momentary Contact Wire Lead Panel Mount Automotive
Verical:
Switch Push Button N.O. SPST Round Plunger 5A 48VAC 48VDC Momentary Contact Panel Mount Wire Lead Automotive
Newark:
# APEM IPR3FAD6 Pushbutton Switch, On-On, SPST-NO, 250 V, 50 V, 500 mA, Wire Leaded
MASTER:
Switch Push Button N.O. SPST Round Plunger 5A 48VAC 48VDC Momentary Contact Panel Mount Wire Lead Automotive
Powell:
IP67 Sealed Pushbutton Switch
Electro Sonic:
Switch Push Button N.O. SPST Round Plunger 5A 48VAC 48VDC Momentary Contact Panel Mount Wire Lead Automotive
额定电压DC 50 V
接触器类型 Button
额定电压AC 48 V
额定电流 500mA AC, 200mA DC
方向 Vertical
触点类型 SPST-NO
额定电流Max 5 A
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压 250 VAC
安装方式 Panel
封装 -
高度 27 mm
封装 -
触点材质 Silver
工作温度 -40℃ ~ 125℃
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
HTS代码 8536509031
