JF 系列 超薄 密封 单刀单掷 3 N 直 通孔 轻触开关
顶部触动 触摸 SPST-NO 通孔
立创商城:
JF15CP2G
得捷:
SWITCH TACTILE SPST-NO 0.05A 24V
贸泽:
触觉开关 SPST RND/RND BLUE
艾睿:
Wow! This ultra-thin JF15CP2G tactile switch from NKK Switches is easy for turning on your circuit with applied force. It has a SPST configuration. This device has a maximum current rating of 0.05 A @ 24VDC. This tactile switch has a minimum operating temperature of -25 °C and a maximum of 85 °C. The JF15CP2G tactile switch has a PC pin termination style. This product is 17.7 mm long, 5.08 mm tall and 17.7 mm deep. The maximum DC voltage rating is 24 VDC. This blue flush round button actuator is 0 mm long.
Allied Electronics:
Switch; Sealed; Tactile; SPST; OFF-ON; Round; Non-Illum; Blue Actuator; 0.05A; 24VDC; PC
Chip1Stop:
Switch Tactile OFF ON SPST Flush Round Button PC Pins 0.05A 24VDC 500000Cycles 3N Thru-Hole
Verical:
Switch Tactile OFF ON SPST Flush Round Button PC Pins 0.05A 24VDC 500000Cycles 3N Thru-Hole
Newark:
# NKK SWITCHES JF15CP2G Tactile Switch, Non Illuminated, 24 V, 50 mA, 3 N, Solder, JF Series
Powell:
ULTRA THIN TACTILE/PC
触点电镀 Silver
额定电压DC 24 V
绝缘电阻 500 MΩ
排数 2
触点类型 SPST
额定电流Max 0.05A @24VDC
工作温度Max 85 ℃
工作温度Min -25 ℃
额定电压 24 VDC
接触电阻Max 50 mΩ
安装方式 Through Hole
封装 -
长度 17.7 mm
宽度 17.7 mm
高度 5.08 mm
封装 -
颜色 Blue
触点材质 Phosphor Bronze
工作温度 -25℃ ~ 85℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
