硅500毫安低噪声齐纳二极管 SILICON 500mA LOW NOISE ZENER DIODES
The 1N4099-1 through 1N4135-1 and 1N4614-1 through 1N4627-1 series are 500 mW, Zener voltage regulators in the axial-leaded, glass DO-35 package. Voltages from 1.8 to 100V in 5%, 2%, and 1% tolerances are available. They are constructed with an internal metallurgical bond and are mil-qualified up to the JANS level for high reliability applications.
贸泽:
Zener Diodes Zener Voltage Regulator Diode
艾睿:
If you need a diode to operate in the reverse breakdown region then use a voltage regulator JAN1N4125-1 zener diode from Microsemi. This device has a maximum regulator current of 8.1 mA. Its maximum leakage current is 0.01 μA. Its maximum power dissipation is 500 mW. Its test current is 0.25 mA. It is made in a single configuration. This zener device has a nominal voltage of 47 V and a voltage tolerance of 5%. This zener diode has a minimum operating temperature of -65 °C and a maximum of 175 °C.
Chip1Stop:
Diode Zener Single 47V 5% 500mW 2-Pin DO-35
Verical:
Zener Diode Single 47V 5% 250Ohm 500mW 2-Pin DO-35 Bag
