硅500 mW的稳压二极管 Silicon 500 mW Zener Diodes
The popular 1N957BUR-1 through 1N992BUR-1 series of 0.5 watt Zener voltage regulators provides a selection from 6.8 to 200 volts in a standard 5%, 2% and 1% tolerance versions. These glass MELF DO-213AA Zeners feature an internal metallurgical bond and are available in military qualified and commercial RoHS compliant versions. Military qualified versions are available on the 1N962BUR-1 through 1N992BUR-1 range of part numbers.
艾睿:
Need to run a diode in the breakdown region? No problem, use a voltage regulator JANTX1N969BUR-1 zener diode from Microsemi. Its maximum power dissipation is 500 mW. Its test current is 5.6 mA. This device has a maximum regulator current of 17 mA. Its maximum leakage current is 0.5 μA. This zener diode has a minimum operating temperature of -65 °C and a maximum of 175 °C. It is made in a single configuration. This zener device has a nominal voltage of 22 V and a voltage tolerance of 5%.
Chip1Stop:
Diode Zener Single 22V 5% 500mW 2-Pin DO-213AA
Verical:
Diode Zener Single 22V 5% 500mW 2-Pin DO-213AA
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
JANTX1N969BUR-1 Microsemi 美高森美 | 当前型号 | 当前型号 |
JANTXV1N969BUR-1 美高森美 | 类似代替 | JANTX1N969BUR-1和JANTXV1N969BUR-1的区别 |
JAN1N969BUR-1 美高森美 | 类似代替 | JANTX1N969BUR-1和JAN1N969BUR-1的区别 |
CDLL969B 美高森美 | 功能相似 | JANTX1N969BUR-1和CDLL969B的区别 |
