XP POWER JCJ1024D12 Isolated Board Mount DC-DC Converter, 2:1Input, Fixed, 2 Output, 18V, 36V, 10W, 12V
JCJ Series, 8/10 Watts. 2:1 Input Range. DIP-24 Metal Package. Operating Temperature -40 °C to +100 °C. Single & Dual Outputs. Continuous Short Circuit Protection. 1500 VDC Isolation. 3 Year Warranty.
得捷:
DC DC CONVERTER +/-12V 10W
Allied Electronics:
Power Supply; DC-DC; 10WATT; DUAL OUTPUT
Newark:
# XP POWER JCJ1024D12 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 2 Output, 18 V, 36 V, 10 W, 12 V
电源电压DC 24.0 V
额定功率 10 W
输出接口数 2
输入电压DC 18.0V ~ 36.0V
输出电压 12 VDC
输出电流 416 mA
输出功率 10 W
隔离电压 1.5 kV
输入电压Max 36 V
输入电压Min 18 V
输入电压DC Max 36 V
输入电压DC Min 18 v
输出电流Max 416mA, 416mA
输出功率Max 10 W
输入电压 18VDC ~ 36VDC
安装方式 Through Hole
封装 DIP-11
宽度 20.32 mm
高度 10.16 mm
封装 DIP-11
重量 20.0 g
工作温度 -40℃ ~ 100℃
产品生命周期 Active
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
