XP POWER JTL3048D15 Isolated Board Mount DC-DC Converter, 4:1Input, Fixed, 2 Output, 18V, 75V, 30W, 15V
JTL Series, 30 Watts. 4:1 Input Range. High Power Density. Single, Dual and Triple Outputs. High Efficiency Up to 91%. Remote On/Off. 1600 VDC Isolation. 3 Year Warranty.
得捷:
DC DC CONVERTER +/-15V 30W
Allied Electronics:
Power Supply; DC/DC CONVERTER +/-15V 30W
Newark:
# XP POWER JTL3048D15 Isolated Board Mount DC/DC Converter, 4:1 Input, Fixed, 2 Output, 18 V, 75 V, 30 W, 15 V
电源电压DC 48.0 V
额定功率 30 W
输出接口数 2
输入电压DC 18.0V ~ 75.0V
输出电压 15 VDC
输出电流 1.00 A
输出功率 30 W
隔离电压 1.6 kV
输入电压Max 75 V
输入电压Min 18 V
输入电压DC Max 75 V
输入电压DC Min 18 v
输出电流Max 1A, 1A
输出功率Max 30 W
输入电压 18VDC ~ 75VDC
安装方式 Through Hole
封装 DIP-7
宽度 25.4 mm
高度 10.16 mm
封装 DIP-7
工作温度 -40℃ ~ 75℃
产品生命周期 Active
包装方式 Tube
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
