XP POWER JTL3048T0515 直流/直流转换器, 隔离电路板安装, 4:1输入, 通孔安装, 30W, 5V, 4A, 15V, 330mA, -15V, 330mA
JTL Series, 30 Watts. 4:1 Input Range. High Power Density. Single, Dual and Triple Outputs. High Efficiency Up to 91%. Remote On/Off. 1600 VDC Isolation. 3 Year Warranty.
得捷:
DC DC CONVERTER 5V +/-15V 30W
e络盟:
XP POWER JTL3048T0515 直流/直流转换器, 隔离电路板安装, 4:1输入, 通孔安装, 30W, 5V, 4A, 15V, 330mA, -15V, 330mA
Allied Electronics:
Power Supply; DC/DC CONVERTER 5V +/-15V
Newark:
# XP POWER JTL3048T0515 Isolated Board Mount DC/DC Converter, 4:1 Input, Fixed, 3 Output, 18 V, 75 V, 30 W, 5 V
电源电压DC 48.0 V
额定功率 30 W
输出接口数 3
输入电压DC 18V ~ 75V
输出电压 5 VDC
输出电流 4.00 A
输出功率 30 W
隔离电压 1.6 kV
输入电压Max 75 V
输入电压Min 18 V
输入电压DC Max 75 V
输入电压DC Min 18 v
输出功率Max 30 W
输入电压 18VDC ~ 75VDC
安装方式 Through Hole
封装 DIP-7
宽度 25.4 mm
高度 10.16 mm
封装 DIP-7
工作温度 -40℃ ~ 75℃
产品生命周期 Active
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
