Circuit Breaker, Molded Case, J-Frame, 2Pole 250A, 600VAC/250VDC, Line/Load:Lug
**Overview** Well-suited to a wide range of applications, the PowerPact® H- and J-Frame Molded Case Circuit Breakers provide a full complement of field installable accessories, field installable trip units and improved interrupting ratings. These molded case circuit breakers deliver unmatched design flexibility for 15 to 250 A applications and share identical mounting holes, handle locations, trim dimensions and accessories, allowing customers to standardize equipment designs for 15 to 250 A applications. **Features
* **
* H-Frame — 150 A Available in Both Standard and 100% Ratings with Standard Amperage Ratings from 15 to 150 A. Interrupting Ratings AIR Include D-18 kA, G-35 kA, J-65 kA and L-100 kA at 480 VAC
* J-Frame — 250 A Available in Both Standard and 100% Ratings with Standard Amperage Ratings from 150 to 250 A. Interrupting Ratings AIR Include D-18 kA, G-35 kA, J-65 kA, and L-100 kA at 480 VAC
* Field Installable Accessories Are Common for H- and J-Frame Circuit Breakers to Make Stocking and Installation Easy
* Unique Snap-In Terminals Make Converting Bus Bar and Lug Configurations Simple and Easy
* Field-Installable Trip Units Lower Inventory Costs and Reduce Stocking Space By Configuring Products at Point of Use
* Allows Design Standardization for 15 to 250 A Applications with Common Mounting Holes, Handle Locations, and Trim Dimensions for Both H- and J-Frame
* Many Configuration Options Provide Application Flexibility, with I-Line®, Plug-In, Drawout, Rear Connected, Distribution Lug, Crimp Lug and Din-Rail Configurations
* Motor Operators, Rotary Handles and Cable Operators Provide Options for Integrating into a Variety of Applications
* Certified to Global Standards, Including UL, IEC, CSA and NOM. Also Marine Ratings **Specifications**
* All Breakers Rated 600 VAC
* Ampere Interrupting Ratings: 25 k @ 240 VAC, 18k @ 480 VAC
* Standards: UL489, CSA, NOM, IEC 60947, CE
