JANTX1N5639A

1500 WATT单向瞬态电压抑制器 1500 WATT UNIDIRECTIONAL TRANSIENT VOLTAGE SUPPRESSOR

DESCRIPTION

This popular Transient Voltage Suppressor TVS series for 1N5629 thru 1N5665A are JEDEC registered selections for unidirectional devices. All have the same high Peak Pulse Power rating of 1500 W with extremely fast response times. They are also available in military qualified selections as

described in the Features section herein.

立创商城:
Vrwm:15.3V 1.5kW

艾睿:
Protect your electronic equipment from sudden or momentary overvoltage conditions with this JANTX1N5639A TVS diode from Microsemi. Its maximum leakage current is 5 μA. This device&s;s maximum clamping voltage is 25.2 V and minimum breakdown voltage is 17.1 V. Its peak pulse power dissipation is 1500 W. Its test current is 1 mA. This TVS diode has a minimum operating temperature of -65 °C and a maximum of 175 °C.

Verical:
TVS Diode Single Uni-Dir 15.3V 1.5KW 2-Pin DO-13 Bag
