KTIR0611S概述
KINGBRIGHT KTIR0611S 透射光中断, 光晶体管, 50 mA
The is a Transmissive Photo Interrupter with phototransistor output. This photo interrupter features low collector-emitter saturation voltage. Suitable for optical control equipment, cameras and floppy disk drives.
- .
- Ultra-small
- .
- Minimal influence from stray light
- .
- 75mW Power dissipation
- .
- -25 to 85°C Operating temperature range
KTIR0611S中文资料参数规格
技术参数
输出电流 20.0 mA
正向电压 1.2 V
输入电流 50.0 mA
峰值波长 940 nm
耗散功率 75 mW
正向电流 50 mA
正向电流Max 50 mA
下降时间Max 20000 ns
上升时间Max 25000 ns
工作温度Max 85 ℃
工作温度Min -25 ℃
耗散功率Max 75 mW
封装参数
安装方式 Through Hole
引脚数 4
其他
产品生命周期 Active
制造应用 Computers & Computer Peripherals, Computers & Computer Peripherals, Imaging, Video & Vision, Imaging, Video & Vision
符合标准
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
海关信息
ECCN代码 EAR99
