AC/DC PCB安装电源 供电单元, ITE & 医用, 1输出, 15 W, 5 V, 3 A
The is a 5V/15W 1-output PCB mount Power Supply features small size and lightweight design with a wide range input, high efficiency, greater than 105%, hiccup mode, automatic recovery over-current and overvoltage protection. KM-series minimises PCB space, global use with no manual intervention and lower heat dissipated in system. This power supply output is fixed.
- .
- Class-II no ground needed
- .
- 50mV Ripple and noise
- .
- 20ms Hold-up time
- .
- 78% Efficiency
- .
- -25 to 70°C Operating temperature range
电源电压DC 264 V
额定功率 15 W
输出接口数 1
输出电压 5 V
输出电流 3 A
输出功率 15 W
输入电压DC Max 375 V
输入电压DC Min 100 V
输入电压AC Max 264 v
输入电压AC Min 90 v
输出电流Max 3 A
输入电流Min 0.8 a
输出功率Max 15 W
工作温度Max 70 ℃
工作温度Min -25 ℃
电源电压 264 V
电源电压Max 264 V
电源电压Min 90 V
输入电压AC 90V ~ 264V
输入电压 90VAC ~ 264VAC
安装方式 Through Hole
引脚数 4
封装 MODULE
长度 23.5 mm
宽度 45.466 mm
高度 23.368 mm
封装 MODULE
产品生命周期 Active
制造应用 Portable Devices, 便携式器材, 医用, Power Management, Medical, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
