对比图
型号 BZW04-23HE3/73 BZW04-23-E3/73 P4KE27A-E3/73
描述 Diode TVS Single Uni-Dir 23.1V 400W 2Pin DO-204AL Tape and AmmoDiode TVS Single Uni-Dir 23.1V 400W 2Pin DO-204AL AmmoESD 抑制器/TVS 二极管 400W 27V Unidirect
数据手册 ---
制造商 Vishay Semiconductor (威世) Vishay Semiconductor (威世) Vishay Semiconductor (威世)
分类 TVS二极管TVS二极管TVS二极管
安装方式 Through Hole Through Hole Through Hole
封装 DO-204AL DO-204AL DO-204AL-2
引脚数 - - 2
脉冲峰值功率 400 W 400 W 400 W
最小反向击穿电压 25.7 V 25.7 V 25.7 V
工作电压 - - 23.1 V
击穿电压 - - 25.7 V
耗散功率 - - 400 W
钳位电压 - - 37.5 V
工作温度(Max) - - 175 ℃
工作温度(Min) - - -55 ℃
封装 DO-204AL DO-204AL DO-204AL-2
工作温度 -55℃ ~ 175℃ (TJ) -55℃ ~ 175℃ (TJ) -55℃ ~ 175℃ (TJ)
产品生命周期 Active Active Active
包装方式 Ammo Pack Ammo Pack Ammo Pack
RoHS标准 RoHS Compliant RoHS Compliant RoHS Compliant
含铅标准 Lead Free Lead Free Lead Free
