对比图
型号 SMP2-SBWC SMTL2-SBWC
描述 Bivar SMP2 Series LEDsThe SMP2 series, from Bivar, are in the industry standard PLCC-2 package. They offer a high luminous intensity alongside a wide viewing angle in a variety of colour options. The SMP2 LEDs have a compact, low profile package which is ideal for applications where space is limited. The PLCC-2 package is also robust and therefore suitable for use in a variety of environmental conditions. With long life reliability and low power consumption, the SMP2 series of LEDs are suitable for use in battery power equipment. Other suitable applications include illumination, general indication and backlighting. The SMP2 LEDs can also be used in clusters for high luminous applications. ### 可见光 LED，BivarLED, SMD, PLCC2, Super Blue, 470nm, 285mcd, Water Clear, 120Deg Viewing Angle
数据手册 --
制造商 Bivar Bivar
分类 发光二极管光源与发射器
安装方式 Surface Mount Surface Mount
引脚数 2 2
封装 PLCC-2 PLCC-2
正向电压 3.2 V 3.2 V
波长 470 nm 470 nm
视角 120° 120°
测试电流 20 mA 20 mA
正向电压(Max) - 3.5 V
正向电流(Max) - 30 mA
工作温度(Max) 85 ℃ 85 ℃
工作温度(Min) -40 ℃ -40 ℃
耗散功率(Max) - 100 mW
额定功率 100 mW -
针脚数 2 -
发光强度 285 mcd -
峰值波长 470 nm -
正向电流 20 mA -
封装 PLCC-2 PLCC-2
长度 3.2 mm -
宽度 2.8 mm -
高度 2.00 mm -
颜色 Blue Blue
外观颜色 Transparent -
产品生命周期 Active Active
包装方式 Tape & Reel (TR) Tape & Reel (TR)
RoHS标准 RoHS Compliant RoHS Compliant
含铅标准 Lead Free 无铅
