Cap Ceramic 20pF 100V C0G 10% SMD 0805 125℃ T/R
SMD Comm C0G, Ceramic, Commercial Grade, 20 pF, 10%, 100 VDC, C0G, SMD, MLCC, Ultra-Stable, Low Loss, Class I, 0805
立创商城:
20pF ±10% 100V
得捷:
CAP CER 20PF 100V NP0 0805
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 100volts 20pF C0G 10%
艾睿:
This C0805C200K1GACTU multilayer ceramic capacitor from Kemet offers high stability and low losses for resonant circuit applications. It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 10%. This product is 2 mm long, 0.78 mm tall and 1.25 mm deep. Its capacitance value is 20pF.
安富利:
Cap Ceramic 20pF 100V C0G 10% SMD 0805 125°C Plastic T/R
额定电压DC 100 V
绝缘电阻 100 GΩ
电容 20 pF
容差 ±10 %
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装公制 2012
封装 0805
引脚间距 0.75 mm
长度 2 mm
宽度 1.25 mm
高度 0.78 mm
封装公制 2012
封装 0805
引脚间距 0.75 mm
介质材料 Ceramic
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C0805C200K1GACTU KEMET Corporation 基美 | 当前型号 | 当前型号 |
C0805HQN101-206KG6P Venkel | 功能相似 | C0805C200K1GACTU和C0805HQN101-206KG6P的区别 |
