AC/DC PCB安装电源 供电单元, ITE, 1输出, 30 W, 48 V, 630 mA
This AC to DC power supply from Mean-Well USA, Inc. safely converts alternating currents into direct currents that your electronic devices can make use of. It has a voltage of 48 V and maximum output power of 30.2 W. This part"s single output can handle a current up to 0.63 A. This part has a minimum operating temperature of -30 °C and a maximum of 70 °C.
欧时:
Power Supply Encapsulated PCB 48V 30W
得捷:
AC/DC CONVERTER 48V 30W
e络盟:
AC/DC PCB安装电源 供电单元, ITE, ITE, 1输出, 30 W, 48 V, 630 mA
艾睿:
AC/DC Power Supply Single-OUT 48V 0.63A 30.2W 4-Pin
Jameco:
Miniature AC-DC Module type Power Supply 48 Volts 0.63 Amps 30.2 Watts
安富利:
AC/DC Power Supply Single-OUT 48V 0.63A 30.2W 4-Pin
TME:
Pwr sup.unit: switched-mode; modular; 30.2W; 48VDC; 69.5x39x24mm
Electro Sonic:
AC/DC Power Supply - 1 Output - 48V@0.63A - 30.2W - Module
CDI:
30W Encapsulated Board Mount Module AC/DC Power Supply with 48VDC Output
额定功率 30.2 W
输出接口数 1
输出电压 48 V
输出电流 0.63 A
输出功率 30.2 W
输入电压AC Max 264 V
输入电压AC Min 85 V
额定电流Max 0.75 A
输出电流Max 0.63 A
输入电流Min 0.75 A
输出功率Max 30 W
工作温度Max 70 ℃
工作温度Min -30 ℃
电源电压 85.264 VAC
输入电压 85V ~ 264V
安装方式 Through Hole
引脚数 4
封装 DIP-4
长度 2.73 in
宽度 1.54 in
高度 0.95 in
封装 DIP-4
重量 109 g
工作温度 -30℃ ~ 70℃
产品生命周期 Unknown
制造应用 ITE(商业)
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
