PWM Pulse Width Modulation Controllers, Texas Instruments
PWM 控制器,1MHz,LM50xx 系列,Texas Instruments
### PWM Pulse Width Modulation Controllers, Texas Instruments
得捷:
IC REG CTRLR MULT TOP 16TSSOP
立创商城:
升降压型 15V~90V 200kHz 600kHz
德州仪器TI:
Cascaded PWM controller with Hiccup mode
欧时:
### PWM 控制器,1MHz,LM50xx 系列,Texas Instruments### PWM Pulse Width Modulation Controllers, Texas Instruments
e络盟:
TEXAS INSTRUMENTS LM5041MTC/NOPB 级联控制器, PWM, 90V-15V电源, 600 kHz, 5V/10mA输出, TSSOP-16
艾睿:
Using the LM5041MTC/NOPB pulse-width modulated controller, developed by Texas Instruments, easily regulate the amount of voltage entering your external circuit. Its typical operating supply voltage is 9 V. Its single PWM output produces a current of 1500 mA. This current mode controller supports boost|buck|half-bridge|push-pull topology. Its switching regulator has a frequency of 600Typ kHz. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This current mode controller&s;s maximum duty cycle is 50Typ %. This device has a typical operating supply voltage of 9 V. Its minimum operating supply voltage of 8.7 V, while its maximum is 9.3 V. This current mode controller has an operating temperature range of -40 °C to 125 °C.
安富利:
Current Mode PWM Controller 1.5A 16-Pin TSSOP Rail
Verical:
Current Mode PWM Controller 1.5A 600kHz 16-Pin TSSOP Tube
Newark:
# TEXAS INSTRUMENTS LM5041MTC/NOPB Cascaded PWM Controller, 90V-15V supply, 600 kHz, 5V/10mA out, TSSOP-16
DeviceMart:
IC REG CTRLR PWM CM 16TSSOP
频率 600 kHz
电源电压DC 15.0V min
输出接口数 1
输入电压DC 48.0V ~ 00V
输出电压 5 V
输出电流 10 mA
供电电流 3 mA
针脚数 16
上升时间 20 ns
输出功率 500 W
开关频率 200kHz, 600kHz
占空比 50 %
最大占空比 50 %
下降时间 20 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 15V ~ 90V
电源电压Max 90 V
电源电压Min 15 V
输入电压 48 V
安装方式 Surface Mount
引脚数 16
封装 TSSOP-16
长度 5 mm
宽度 4.4 mm
高度 0.9 mm
封装 TSSOP-16
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM5041MTC/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM5041MTCX 德州仪器 | 完全替代 | LM5041MTC/NOPB和LM5041MTCX的区别 |
LM5041MTCX/NOPB 德州仪器 | 类似代替 | LM5041MTC/NOPB和LM5041MTCX/NOPB的区别 |
LM5041MTC 德州仪器 | 功能相似 | LM5041MTC/NOPB和LM5041MTC的区别 |
