LQW15AN91NG00D

MURATA  LQW15AN91NG00D  表面贴装高频电感器, LQW15AN系列, 91 nH, ± 2%, 0402 [1005 公制], 2.1 GHz, 2.38 ohm

Murata 0402 LQW15AN_00D 系列线绕器 0.051μH - 0.12μH

高质量线圈电感器，设计用于 VHF 和 UHF 应用。

高谐振频率。

低容差电感值。

应用：高频率电路，用于无线电信设备，例如蓝牙、GSM、W-LAN。

欧时:
Murata LQW15A 系列 铁氧体芯材 91 nH 绕线贴片电感器 LQW15AN91NG00D, ±2%容差, 125mA Idc Q:20

得捷:
FIXED IND 91NH 125MA 2.38OHM SMD

立创商城:
91nH ±2% 2.38Ω

e络盟:
高频电感器, 91 nH, LQW15AN系列, 125 mA, 0402 [1005 公制], 非屏蔽, 2.38 ohm

艾睿:
Use this rf chip LQW15AN91NG00D surface mount inductor from Murata to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has an inductance of 91n H. It has a tolerance of 2%. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 2.1G Hz. This SMD inductor has a maximum DC current of 125m A with a maximum resistance of 2.38 Ohm. This product is 1.1 mm long, 0.6 mm tall and 0.6 mm deep. This device utilizes wirewound technology.

安富利:
Ind RF Chip Wirewound 91nH 2% 100MHz 20Q-Factor 125mA 0402 Paper T/R

Chip1Stop:
Inductor RF Chip Wirewound 91nH 2% 100MHz 20Q-Factor 125mA 2.38Ohm DCR 0402 Paper T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.091uH 2% 100MHz 20Q-Factor Non Magnetic 0.125A 2.38Ohm DCR 0402 T/R

Newark:
# MURATA  LQW15AN91NG00D  Surface Mount High Frequency Inductor, LQW15AN Series, 91 nH, 2%, 0402 [1005 Metric], 2.1 GHz

儒卓力:
**LQW15A 91nH 125mA 2% WWT **

Win Source:
91nH Unshielded Wirewound Inductor 125mA 2.38 Ohm Max 0402 1005 Metric
