LD1117S12CTR

LD1117 系列 15V 950mA 可调节和固定 低压差 正电压 稳压器

线性稳压器，800mA，STMicroelectronics

欧时:
STMicroelectronics LD1117S12CTR LDO 稳压器, 1.2 V输出, 1.3A最大输出, ±1%精确度, 3+Tab引脚 SOT-223封装

得捷:
IC REG LINEAR 1.2V 800MA SOT223

立创商城:
正 Vin=15V Vout=1.2V~1.2V 800mA 75dB@120Hz

贸泽:
低压差稳压器 Low drop fixed Adj pos volt reg

艾睿:
Don&s;t let unpredictable voltage levels ruin your circuit! Use this LDO LD1117S12CTR linear regulator from STMicroelectronics to control your voltage levels! It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 1@100mA|1.05@500mA|1.1@800mA V. This device has a maximum power dissipation of 12000 mW. This voltage regulation device&s;s single output can produce a current up to 1.3 A. The best way to provide power to your application is by using this, which needs a voltage lower than 15 V. With a fixed output that has a voltage of 1.2 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 1% and line regulation of 1%. Its maximum power dissipation is 12000 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. The maximum dropout voltage is 1.1@100mA|1.15@500mA|1.2@800mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.

安富利:
LDO Regulator Pos 1.2V 1.3A 4-Pin3+Tab SOT-223 T/R

富昌:
LD1117 Series 1300 mA 1.2 V Fixed Output Positive Voltage LDO Regulator- SOT-223

Chip1Stop:
LDO Regulator Pos 1.2V 1.3A 4-Pin3+Tab SOT-223 T/R

Verical:
LDO Regulator Pos 1.2V 1.3A 4-Pin3+Tab SOT-223 T/R

儒卓力:
**LDO.VREG POS 1,2V 1A SOT223 **

力源芯城:
1.2V低压差稳压器

DeviceMart:
IC REG LDO 1.2V .95A SOT-223

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.2V 800mA SOT-223
