多相位 6 核降压转换器 49-DSBGA -40 to 85
The LP8754 is designed to meet the power management requirements of the latest applications processors in mobile phones and similar portable applications. The device contains six step-down DC/DC converter cores, which are bundled together in a 6-phase buck converter. The device is fully controlled by a Dynamic Voltage Scaling DVS interface or an I2C-compatible serial interface.
The automatic PWM/PFM operation together with the automatic phase adding/shedding maximizes efficiency over a wide output current range. The LP8754 supports remote differential voltage sensing to compensate IR drop between the regulator output and the point-of-load thus improving the accuracy of the output voltage.
The protection features include short-circuit protection, current limits, input OVP, UVLO, temperature warning, and shutdown functions. Several error flags are provided for status information of the IC. In addition, I2C read-back includes total load current and load current for each buck core: The LP8754 has the ability to sense current being delivered to the load without the addition of current sense resistors. During start-up, the device controls the output voltage slew rate to minimize overshoot and the inrush current.
输出接口数 1
输出电压 0.6V ~ 1.67V
输出电流 10 A
静态电流 80.0 µA
调节输出数 1
开关频率 3 MHz
拓扑结构 Buck
开关电流 2.6 A
输入电压Max 5 V
输入电压Min 2.5 V
输出电压Max 1.67 V
输出电压Min 0.6 V
输出电流Max 10 A
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 5 V
安装方式 Surface Mount
引脚数 49
封装 DSBGA-49
封装 DSBGA-49
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
