LINEAR TECHNOLOGY LTC3861EUH-1#PBF 降压控制器, 双路, 5.5V-3V电源, 2.25 MHz, 5.5V/60A输出, QFN-32
Do you have to step up or down from one voltage level to another? The synchronous step down DC voltage controller gives you the ability to do just that. This DC voltage controller has 2 outputs. This DC voltage controller has an input voltage of 3 to 24 V. You can operate this at a switching frequency of 2250 kHz. This DC voltage controller has an operating temperature range of -40 °C to 125 °C.
频率 2.25 MHz
电源电压DC 3.00V min
输出接口数 2
输入电压DC 24.0 V
输出电压 5.5 V
输出电流 60 A
针脚数 32
开关频率 250kHz ~ 3MHz
占空比 91.5 %
输入电压Max 24 V
输入电压Min 3 V
最大占空比 0.915
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 3V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 3 V
输入电压 24 V
安装方式 Surface Mount
引脚数 32
封装 QFN-32
封装 QFN-32
工作温度 -40℃ ~ 125℃
产品生命周期 Unknown
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LTC3861EUH-1#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LTC3861EUH-1#TRPBF 凌力尔特 | 完全替代 | LTC3861EUH-1#PBF和LTC3861EUH-1#TRPBF的区别 |
