标准LED-SMD Orange, 606nm 224mcd, 20mA
Orange 606nm Indication - Discrete 2V 2-SMD, J-Lead
得捷:
LED ORANGE CLEAR SMD
贸泽:
标准LED-SMD Orange, 606nm 224mcd, 20mA
艾睿:
LED Uni-Color Orange 610nm Automotive 2-Pin SMD T/R
安富利:
LED Uni-Color Orange 610nm 2-Pin SMT T/R
Chip1Stop:
LED Uni-Color Orange 610nm Automotive 2-Pin SMD T/R
Verical:
LED Uni-Color Orange 610nm Automotive 2-Pin SMD T/R
正向电压 2 V
波长 606 nm
发光强度 224 mcd
视角 120°
透镜样式 Non-Diffused
峰值波长 610 nm
耗散功率 80 W
测试电流 20 mA
正向电流 30 mA
正向电压Max 2.35 V
正向电流Max 30 mA
工作温度Max 100 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 2
封装 SMD-2
长度 2.1 mm
宽度 1.5 mm
高度 1.25 mm
封装 SMD-2
颜色 Orange
工作温度 -40℃ ~ 100℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LO M676-Q2S1-24-Z Osram Opto 欧司朗 | 当前型号 | 当前型号 |
LO M676-R1S2-24 欧司朗 | 完全替代 | LO M676-Q2S1-24-Z和LO M676-R1S2-24的区别 |
