SMD LED Non-standard Yellow 112mcd 120° 20mA 2V OSRAM
黄色 587nm 指示 - 分立 2V 2-SMD,Boomerang
艾睿: LED Uni-Color Yellow 591nm Automotive 2-Pin SMD T/R
正向电压 2 V
波长 587 nm
视角 120°
峰值波长 591 nm
测试电流 20 mA
正向电压Max 2.4 V
正向电流Max 30 mA
工作温度Max 100 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 2
封装 SMD-2
宽度 4.2 mm
高度 4.20 mm
颜色 Yellow
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
