LQW2BHN21NK13L

Murata 0805 LQW2BH_13 系列线绕电感器工作温度：-40 → +85°C 尺寸：2.0 x 1.5 x 1.75 mm 封装类型：0805 ### 表面安装 0805 电感器（扼流圈）

Murata 0805 LQW2BH_13 系列线绕器

工作温度：-40 → +85°C

尺寸：2.0 x 1.5 x 1.75 mm

封装类型：0805

立创商城:
21nH ±10% 50mΩ

得捷:
FIXED IND 21NH 950MA 50 MOHM SMD

欧时:
Murata LQW2BH_13 系列 铁氧体芯材 21 nH 绕线贴片电感器 LQW2BHN21NK13L, ±10%容差, 950mA Idc Q:40

艾睿:
This rf chip LQW2BHN21NK13L surface mount inductor from Murata is ideal for saving valuable space on a PCB. This SMD inductor has an operating temperature range of -25 °C to 85 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This SMD inductor has a maximum DC current of 950m A with a maximum resistance of 50m Ohm. This device utilizes wirewound technology. It has an inductance of 21n H. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 2.2G Hz. It has a tolerance of 10%. This product is 2.2 mm long, 1.78 mm tall and 1.7 mm deep.

安富利:
Ind RF Chip Wirewound 21nH 10% 100MHz 40Q-Factor 950mA 0805 Embossed T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.021uH 10% 100MHz 40Q-Factor Non Magnetic 0.95A 0.05Ohm DCR 0805 T/R
