LM26480SQ-AA

TEXAS INSTRUMENTS  LM26480SQ-AA  芯片, 线性稳压器, 直流-直流降压, 双路

The is a multi-functional Power Management Unit, optimized for low-power digital applications. This device integrates two highly efficient 1.5A step-down DC-DC converters and two 300mA linear regulators.

.

Compatible with advanced applications processors and FPGAs

.

Two LDOs for powering internal processor functions and I/Os

.

Precision internal reference

.

Thermal overload protection

.

Current overload protection

.

Undervoltage lockout detector to monitor input supply voltage

.

Step-down DC-DC converter - Up to 96% efficiency and 1.5A output current

.

Step-down DC-DC converter - Automatic soft start

.

Step-down DC-DC converter - 2MHz PWM switching frequency

.

Linear regulators LDO - VOUT of 1 to 3.5V and ±3% FB voltage accuracy

.

Linear regulators LDO - 300mA output current and 25mV typical dropout
