LQW2BHN33NJ03L

Murata 0805 LQW2BH 系列线绕电感器工作温度：-40 → +85°C 尺寸：2.0 x 1.5 x 1.75 mm 封装类型：0805 ### 表面安装 0805 电感器（扼流圈）

固定器

立创商城:
33nH ±5% 570mA 150mΩ

得捷:
FIXED IND 33NH 570MA 150MOHM SMD

欧时:
### Murata 0805 LQW2BH 系列线绕电感器工作温度：-40 → +85°C 尺寸：2.0 x 1.5 x 1.75 mm 封装类型：0805 ### 表面安装 0805 电感器（扼流圈）

贸泽:
Fixed Inductors 0805 33nH

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this rf chip LQW2BHN33NJ03L surface mount inductor from Murata is perfect for you! This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 85 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 1.9G Hz. This device is made with wirewound technology. It has an inductance of 33n H. It has a tolerance of 5%. This product is 2.2 mm long, 1.78 mm tall and 1.7 mm deep. This SMD inductor has a maximum DC current of 570m A with a maximum resistance of 150m Ohm.

安富利:
Ind RF Chip Wirewound 33nH 5% 100MHz 40Q-Factor Air 570mA 0805 Embossed T/R

Chip1Stop:
Inductor RF Chip Unshielded Wirewound 33nH 5% 100MHz 40Q-Factor Ceramic 570mA 150mOhm DCR 0805 T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.033uH 5% 100MHz 40Q-Factor Non Magnetic 0.57A 0.15Ohm DCR 0805 T/R

儒卓力:
**LQW2BH 0,033uH 570mA 5% WWT **

Win Source:
FIXED IND 33NH 570MA 150 MOHM
