LTC4441ES8-1

门驱动器 LTC4441 - N-Channel MOSFET Gate Driver

Description

The LTC®4441/LTC4441-1 is an N-channel MOSFET gate driver that can supply up to 6A of peak output current. The chip is designed to operate with a supply voltage of up to 25V and has an adjustable linear regulator for the gate drive. The gate drive voltage can be programmed between 5V and 8V.

Features

6A Peak Output Current

Wide VINSupply Range: 5V to 25V

Adjustable Gate Drive Voltage: 5V to 8V

Logic Input Can Be Driven Below Ground

30ns Propagation Delay

Supply Independent CMOS/TTL Input Thresholds

Undervoltage Lockout

Low Shutdown Current: <12µA

Overtemperature Protection

Adjustable Blanking Time for MOSFET’s Current Sense Signal LTC4441

Available in SO-8 and 10-Lead MSOP Exposed Pad Packages
