MICRO SWITCH™ Premium Large Basic Switches: BM Series, Single Pole Double Throw SPDT, 22A 125/250/480VAC, ENEC 22A 250VAC, 11,9mm [0.47in] Threaded Bushing with 8,3mm [0.326in] Diameter Additional Overtravel Plunger, Binding Head Combination Screw Termination with Cup Washers, Bushing Hardware Furnished Unassembled, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC
MICRO SWITCH™ Premium Large Basic Switches: BM Series, Single Pole Double Throw SPDT, 22 A 125/250/480 Vac, ENEC 22 A 250 Vac, 11,9 mm [0.47 in] Threaded Bushing with 8,3 mm [0.326 in] Diameter Additional Overtravel Plunger, Binding Head Combination Screw Termination with Cup Washers, Bushing Hardware Furnished Unassembled, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC
Product Highlights
Mounting interchangeability with BZ/BA switches
Rated for 10 A resistive at 125 Vac/Vdc and 3 A resistive at 250 Vdc
Mechanical life of 100,000 cycles at 95% survival
Arc-extinguishing design in contact area
Arc-resistant case
Potential Applications:
DC motors
Solenoids
