OP07DRZ-REEL

150 μV最大失调电压运算放大器 150 レV Maximum Offset Voltage Op Amp

GENERAL DESCRIPTION

The OP07D is a precision, ultralow offset amplifier. It integrates low power 1.1 mA typical, low input bias current ±1 nA maximum, and high CMRR/PSRR 130 dB in the small DIP package. Operation is fully specified from ±5 V to ±15 V supply.

FEATURES

Low offset voltage: 150 μV max

Input offset drift: 1.5 μV/°C max

Low noise: 0.25 μV p-p

High gain CMRR and PSRR: 115 dB min

Low supply current: 1.1 mA

Wide supply voltage range: ±4 V to ±18 V operation
