PCK0G331MCO1GS

NICHICON  PCK0G331MCO1GS  铝电解电容, 330uF, 4V, SMD

CK 系列超低 ESR

超低 ESR / 高波纹电流

105°C 时可保证 2000 小时

表面安装型

容差：±20%

工作温度范围 -55 至 +105°C

立创商城:
330uF ±20% 4V

得捷:
CAP ALUM POLY 330UF 20% 4V SMD

欧时:
### CK 系列超低 ESR### 固体贴片 105°C电容容差 | 20 % ---|--- 工作温度 | -40 至 +105°C 耗散因子 | 小于或等于 0.06（120Hz，20°C） 冲击电压 | 额定工作电压 x 1.25（15 至 35°C） 预期寿命 @ 105°C | 1000 小时

e络盟:
铝电解电容, 330uF, 4V, SMD

艾睿:
The PCK0G331MCO1GS polymer capacitor, made from pure aluminum and developed by Nichicon, will handle all of your circuit&s;s voltage control needs. It can withstand a voltage of 4 VDC. It has 2 terminals. It has a tolerance of 20%. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 105 °C. Its leakage current is 396@2Min μA. This product is 6Max mm tall with a diameter of 6.3 mm.

Allied Electronics:
330uF 4V dc Polymer ALUM Electrolytic Capacitor, CK Series 2000h 6.3Dia.x6mm

安富利:
Cap Aluminum 330uF 4V 20% 6.3 X 6mm SMD 0.01 Ohm 3900mA 2000 hr 105°C T/R

Verical:
Cap Aluminum Polymer 330uF 4VDC 20% 6.3 X 6mm SMD 0.01 Ohm 3900mA 2000h 105C Automotive T/R

Newark:
# NICHICON  PCK0G331MCO1GS  Electrolytic Capacitor, 330 µF, 4 V, CK Series, Radial Can - SMD, -55 °C
