PE-1008CD222JTT

1008 2.2uH ±5% 280mA

无屏蔽 绕线 器 2.8 欧姆最大 1008（2520 公制）

得捷:
FIXED IND 2.2UH 280MA 2.8OHM SMD

艾睿:
Save valuable space on a PCB with this rf chip PE-1008CD222JTT surface mount inductor from Pulse. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This device is made with wirewound technology. Its test frequency is 7.9M Hz, while its minimum self-resonant frequency is 80M Hz. It has an inductance of 2.2u H. This SMD inductor has a maximum DC current of 280m A with a maximum resistance of 2.8 Ohm. This product is 2.92 mm long, 2.29 mm tall and 2.79 mm deep. It has a tolerance of 5%.

Chip1Stop:
Ind RF Chip Wirewound 2.2uH 5% 7.9MHz 28Q-Factor Ceramic 280mA 1008 T/R

Verical:
Inductor RF Chip Wirewound 2.2uH 5% 7.9MHz 28Q-Factor Ceramic 0.28A 2.8Ohm DCR 1008 T/R

CDI:
1008 SURFACE MOUNT INDUCTORS Ceramic -LEAD FREE
