DIN导轨式电源 12VDC 5A 60W SINGLE OUTPUT DIN
DIN Rail mountable power supplies have a Universal AC input range of 85-264 V on the single-phase and 350-550 V on the three-phases. They are suitable for industrial and automation applications. This line has a built-in short circuit, overload, over-voltage and over-temperature protection. They are available from 45 W-960 W with standard voltage outputs of 5 V, 12 V, 15 V, 24 V on the lower wattage models, and 24 V and 48 V on the higher wattage units. These high efficiency up to 91% power supplies are cooled by free air convection, have an LED indicator for power on and have a 100% full load burn-in test. They are UL/cUL and CE approved and have a 3-year warranty.
* UL508 Listed
* Installed on DIN Rail TS35/7.5 or 15
* Protections: Short Circuit/Overload/Overvoltage/Over Temperature
* Cooling by Free Air Convection
* Worldwide Approvals
* Universal AC Input
* Three-Year Warranty
额定电流 5 A
输出接口数 1
输出电压 12 V
输出电流 5 A
输出功率 60 W
输入电压DC Max 370 V
输入电压DC Min 120 V
输入电压AC Max 264 V
输入电压AC Min 85 V
输入电流Min 1.8 A
工作温度Max 70 ℃
工作温度Min -20 ℃
额定电压 12 V
输入电压 85VAC ~ 264VAC, 120VDC ~ 370VDC
安装方式 DIN Rail
引脚数 9
长度 100 mm
宽度 40 mm
高度 90 mm
产品生命周期 Obsolete
制造应用 工业，ITE（商用）
RoHS标准 RoHS Compliant
