BOURNS SRP1265A-R15M 表面贴装功率电感器, AEC-Q200 SRP1265A系列, 150 nH, ± 20%, 屏蔽, 600 µohm, 55 A
SRP1265A 系列磁性屏蔽式功率器
Bourns SRP 系列高电流电感器具有羰基粉芯且符合 AEC-Q200。
**特点和优势:**
SRP1265A 系列电感器为带羰基粉芯的屏蔽结构
高饱和电流
电感范围为 0.15 至 47μH
符合 AEC-Q200
符合 RoHS 标准且无卤
应用包括汽车系统(驾驶员辅助、信息、娱乐和照明)、直流-直流转换器和电源
得捷:
FIXED IND 150NH 55A 0.6 MOHM SMD
欧时:
Bourns SRP1265A 系列 屏蔽 羰基粉芯材 150 nH 绕线贴片电感器 SRP1265A-R15M, ±20%容差, 55A Idc
贸泽:
Fixed Inductors 0.15uH 20% SMD 1265 AEC-Q200
e络盟:
BOURNS SRP1265A-R15M 表面贴装功率电感器, AEC-Q200 SRP1265A系列, 150 nH, ± 20%, 屏蔽, 600 µohm, 55 A
艾睿:
Use this power SRP1265A-R15M surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -40 °C to 150 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This SMD inductor has a maximum DC current of 55 A with a maximum resistance of 600u Ohm. This device utilizes wirewound technology. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 210MTyp Hz. It has a tolerance of 20%. This product is 14 mm long, 6.4 mm tall and 12.8 mm deep. It has an inductance of 150n H.
Allied Electronics:
Inductor; Shielded Power; AEC-Q200; 0.15uH20% SMT 1265
安富利:
Ind Power Shielded 0.15uH 20% 100KHz Carbonyl Powder 55A T/R
Chip1Stop:
Inductor Power Shielded Wirewound 150nH 20% 100KHz 10Q-Factor Carbonyl Powder 55A 600uOhm DCR Automotive T/R
Verical:
Inductor Power Shielded Wirewound 0.15uH 20% 100KHz 10Q-Factor Carbonyl Powder 55A 0.0006Ohm DCR Automotive T/R
Newark:
# BOURNS SRP1265A-R15M Surface Mount Power Inductor, SRP1265A Series, 150 nH, 55 A, 118 A, Shielded, 600 µohm
额定电流 55 A
容差 ±20 %
电感 150 nH
自谐频率 210 MHz
Q值 10
电感公差 ±20 %
测试频率 100 kHz
电阻DC) 0.0006 Ω
工作温度Max 150 ℃
工作温度Min -40 ℃
电阻DC Max 0.0006 Ω
安装方式 Surface Mount
封装 13.5mm x 12.5mm x 6.2mm
长度 13.5 mm
宽度 12.5 mm
高度 6.2 mm
封装 13.5mm x 12.5mm x 6.2mm
工作温度 -40℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
