SSCSNBN005PDAA5

HONEYWELL  SSCSNBN005PDAA5  压力传感器, Trustability, 模拟, 5 psi, 差值, 5 VDC, 双轴, 2.7 mA

差分 压力 ±5PSI（±34.47kPa） 公型 - 0.19"（4.8mm）双管 0.5V ~ 4.5V 4-SIP、双端口，同侧

欧时:
SSC Series pressure sensor IC

得捷:
SENSOR 5PSID 0.19" 4.5V 4SIP

立创商城:
SSCSNBN005PDAA5

e络盟:
压力传感器, Trustability, 5 psi, 模拟, 差值, 5 VDC, 双轴, 2.7 mA

艾睿:
Use this SSCSNBN005PDAA5 board mount pressure sensor from Honeywell to ensure that your circuit board is protected from dangerous gas or liquid pressure changes. It has a voltage of 0.5 to 4.5 V. This device&s;s minimum operating supply voltage of 4.75 V, while its maximum is 5.25 V. This part has a temperature range of -40 °C to 85 °C. It has a response time of 1 ms. Its operating pressure range is -5psi to 5psi, while its maximum overload pressure is 30psi. This part has a maximum ESD protection device voltage of 3Min @ HBM kV.

Allied Electronics:
Sensor; Pressure; differential; ±5 psi; 5.0 Vdc; dry gases only

Chip1Stop:
Pressure Sensor 0.5V to 4.5V -5psi to 5psi Differential 4-Pin SIP

MASTER:
TruStability® Board Mount Pressure Sensor - Compensated/Amplified: SSC Series, Standard Accuracy, ± 2% Total Error Band, SIP, Fastener Mount Dual Axial Ports, Same Side, 5 psi Differential, Amplified Analog Output, 10% to 90% Vdd, 5 V Supply, Dry Gases On

Powell:
TruStability Silicon P

GOPHER:
Pressure Sensor DIFFERENTIAL 5 PSI AMPLIFIED SIP 5V MEDIA SIDE-NO PORT,REFERENCE SIDE-DUAL AXIAL SAME SI

Win Source:
SENSOR PRESS 5PSI DIFF 5V SIP / Pressure Sensor ±5PSI ±34.47kPa Differential Male - 0.19" 4.8mm Tube, Dual 0.5 V ~ 4.5 V 4-SIP, Dual Ports, Same Side
