双路4输入正与门 DUAL 4-INPUT POSITIVE-AND GATES
Build any logic circuits you can think of with this logic gate by Texas Instruments. This gate has a minimum operating temperature of -40 °C and a maximum of 85 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
电源电压DC 2.00V ~ 6.00V
输出接口数 1
输出电流 5.20 mA
电路数 2
针脚数 14
位数 2
传送延迟时间 140 ns
电压波节 6.00 V, 4.50 V, 2.00 V
逻辑门个数 2
输出电流驱动 -1.00 mA
输入数 4
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 6V
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 14
封装 TSSOP-14
封装 TSSOP-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74HC21PWR TI 德州仪器 | 当前型号 | 当前型号 |
SN74HC21PWT 德州仪器 | 完全替代 | SN74HC21PWR和SN74HC21PWT的区别 |
SN74HC21PWRE4 德州仪器 | 完全替代 | SN74HC21PWR和SN74HC21PWRE4的区别 |
SN74HC21PWG4 德州仪器 | 完全替代 | SN74HC21PWR和SN74HC21PWG4的区别 |
