SHIELDED SMD功率电感 Shielded SMD Power Inductors
Inductor Power Shielded Wirewound 3.9uH 30% 100KHz 15Q-Factor Ferrite 4.8A 14.6mOhm DCR 3131 T/R
得捷:
FIXED IND 3.9UH 4.8A 14.6MOHM SM
欧时:
Ind8x8x4.3mm,3.9uH30%4.8A,shdSMD
立创商城:
3.9uH ±30% 4.8A 14.6mΩ
艾睿:
Inductor Power Shielded Wirewound 3.9uH 30% 100KHz 15Q-Factor Ferrite 4.8A 0.0146Ohm DCR 3131 T/R
安富利:
Ind Power Shielded Wirewound 3.9uH 30% 100KHz 15Q-Factor Ferrite 4.8A T/R
Verical:
Inductor Power Shielded Wirewound 3.9uH 30% 100KHz 15Q-Factor Ferrite 4.8A 0.0146Ohm DCR 3131 T/R
Newark:
# BOURNS SRU8043-3R9Y Surface Mount Power Inductor, SRU8043 Series, 3.9 µH, 4.8 A, 4 A, Shielded, 0.0146 ohm
Online Components:
Inductor Power Shielded Wirewound 3.9uH 30% 100KHz 15Q-Factor Ferrite 4.8A 14.6mOhm DCR 3131 T/R
Electro Sonic:
Inductor Power Shielded Wirewound 3.9uH 30% 100KHz 15Q-Factor Ferrite 4.8A 14.6mOhm DCR 3131 T/R
额定电流 4.8 A
容差 ±30 %
电感 3.9 µH
自谐频率 42 MHz
Q值 15.0
电阻 14.6 mΩ
共振频率 42.0 MHz
电感公差 ±30 %
测试频率 100 kHz
电阻DC） 14.6 mΩ
工作温度Max 125 ℃
工作温度Min -40 ℃
电阻DC Max 0.0146 Ω
安装方式 Surface Mount
引脚数 2
封装 8043
宽度 8 mm
高度 4.6 mm
封装 8043
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
