SRU3028 系列磁性屏蔽线绕扼流圈超薄型屏蔽结构 高电流额定值。 非常适合于高频率。 应用:直流/直流转换器,EMI 滤波器。 ### Bourns 非标准表面安装电感器(扼流圈)
SRU3028 系列磁性屏蔽线绕扼流圈
超薄型屏蔽结构
高电流额定值。
非常适合于高频率。
应用:直流/直流转换器,EMI 滤波器。
得捷:
FIXED IND 33UH 470MA 450MOHM SMD
立创商城:
33uH ±30% 470mA 450mΩ
欧时:
### SRU3028 系列磁性屏蔽线绕扼流圈超薄型屏蔽结构 高电流额定值。 非常适合于高频率。 应用:直流/直流转换器,EMI 滤波器。 ### Bourns 非标准表面安装电感器(扼流圈)
艾睿:
This power SRU3028-330Y surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This SMD inductor has a maximum DC current of 470m A with a maximum resistance of 450m Ohm. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 10MTyp Hz. This product is 3.5 mm long, 3 mm tall and 3.5 mm deep. This device is made with wirewound technology. It has an inductance of 33u H.
Allied Electronics:
SRU3028 Series Shielded WireWound SMD Inductor w/ Ferrite Core, 33 uH +/-30% Q:20
安富利:
Ind Power Shielded Wirewound 33uH 30% 100KHz 20Q-Factor Ferrite 470mA T/R
Verical:
Inductor Power Shielded Wirewound 33uH 30% 100KHz 20Q-Factor Ferrite 0.47A 0.45Ohm DCR T/R
