SRP7028A-5R6M

BOURNS  SRP7028A-5R6M  表面贴装功率电感器, AEC-Q200 SRP7028A系列, 5.6 µH, ± 20%, 屏蔽, 0.048 ohm, 5 A

SRP7028A 系列磁性屏蔽式功率器

Bourns 汽车 SRP7028A 系列电感器采用屏蔽结构，具有羰基粉芯。

**特点和优势：**

高饱和电流

电感范围为 0.22 至 10μH

符合 AEC-Q200

符合 RoHS 标准且无卤

应用包括汽车系统（驾驶员辅助、信息、娱乐和照明）、直流-直流转换器和电源

立创商城:
5.6uH ±20% 5A 43mΩ

得捷:
FIXED IND 5.6UH 5A 48 MOHM SMD

欧时:
Bourns SRP7028A 系列 屏蔽 羰基粉芯材 5.6 μH 绕线贴片电感器 SRP7028A-5R6M, ±20%容差, 5A Idc

e络盟:
功率电感SMD, 5.6 µH, 5 A, 屏蔽, 9 A, SRP7028A 系列, 7.3mm x 6.6mm x 2.8mm

艾睿:
This power SRP7028A-5R6M surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 150 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has an inductance of 5.6u H. This SMD inductor has a maximum DC current of 5 A with a maximum resistance of 48m Ohm. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 19MTyp Hz. This device is made with wirewound technology. It has a tolerance of 20%. This product is 7.6 mm long, 3 mm tall and 6.9 mm deep.

Allied Electronics:
Inductor; Shielded Power; AEC-Q200; 5.6uH 20% SMT 7028

安富利:
Ind Power Shielded Wirewound 5.6uH 20% 100KHz Carbonyl Powder 5A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz 20Q-Factor Carbonyl Powder 5A 48mOhm DCR Automotive T/R

Verical:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz 20Q-Factor Carbonyl Powder 5A 0.048Ohm DCR Automotive T/R

Newark:
# BOURNS  SRP7028A-5R6M  Surface Mount Power Inductor, AEC-Q200 SRP7028A Series, 5.6 H, 20%, Shielded, 0.048 ohm, 5 A

Online Components:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz 20Q-Factor Carbonyl Powder 5A 48mOhm DCR Automotive T/R

Electro Sonic:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz 20Q-Factor Carbonyl Powder 5A 48mOhm DCR Automotive T/R
