SSA-118-S-T

Conn Socket Strip SKT 18POS 2.54mm Solder ST Thru-Hole

18 Position Receptacle, Breakaway Connector 0.100" 2.54mm Through Hole Tin

得捷:
CONN RCPT 18POS 0.1 TIN PCB

艾睿:
This socket strip SSA-118-S-T header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This SKT connector&s;s 18 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a maximum voltage rating of 1000 VAC. It has a socket type gender. This is a 1-row connector. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 1 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 45.72 mm long, 5.84 mm tall and 2.54 mm deep. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. SSA-118-S-T is housed in black polyethylene terephthalate.

Newark:
# SAMTEC  SSA-118-S-T  LOW COST SOCKET STRIPS
