S-3-G-4-G中文资料参数规格
技术参数
额定电流 5.00 A
外形尺寸
长度 33.3 mm
其他
Brand/Series S Series
Centerline, Spacing 0.125 3.18 In.mm In.mm
Contact Resistance 20 Milliohms Max. Milliohms Max.
Current Rating 5 A A
Force, Spring 4.0 Oz. Oz.
Gender Probe
Length, Overall 1.31 In. In.
Material, Barrel Nickel/Silver
Material, Plating Gold Plated Plunger
Material, Plunger Beryllium Copper
Material, Spring Stainless Steel
Minimum Centers 0.125 In.
Preload 1.8 Oz.
Primary Type Probe
Size Size 3
Tip Style G - Concave 90 Deg
Type General Purpose
Working Travel 0.17
符合标准
RoHS标准 RoHS Compliant
在线购买S-3-G-4-G
型号： S-3-G-4-G
制造商：
IDIInterconnect Devices
描述：Probe, Concave, , Size 3, Spring Force 4oz@.170 Travel, Gld Pltd Plunger
