TMP175AIDG4

数字温度传感器，具有双线接口 Digital Temperature Sensor with Two-Wire Interface

Description

The TMP75 and TMP175 devices are digital temperature sensors ideal for negative temperature coefficient NTC and positive temperature coefficient PTC thermistor replacement. The devices offer a typical accuracy of ±1°C without requiring calibration or external component signal conditioning. Device temperature sensors are highly linear and do not require complex calculations or look-up tables to derive the temperature. The on-chip 12-bit analog-to digital converter ADC offers resolutions down to 0.0625°C. The devices are available in the industry standard LM75 SOIC-8 and MSOP-8 footprint.

Features

• TMP175: 27 Addresses

• TMP75: 8 Addresses, NIST Traceable

• Digital Output: SMBus™, Two-Wire, and I2C Interface Compatibility

• Resolution: 9 to 12 Bits, User-Selectable

• Accuracy:

   – ±1°C Typical from −40°C to +125°C

   – ±2°C Maximum from −40°C to +125°C

• Low Quiescent Current: 50-μA, 0.1-μA Standby

• Wide Supply Range: 2.7 V to 5.5 V

• Small 8-Pin MSOP and 8-Pin SOIC Packages

Applications

• Power-Supply Temperature Monitoring

• Computer Peripheral Thermal Protection

• Notebook Computers

• Cell Phones

• Battery Management

• Office Machines

• Thermostat Controls

• Environmental Monitoring and HVAC

• Electro Mechanical Device Temperature
