低价双插槽PC卡电源开关,用于串行PCMCIA CONTROLLERS LOW-COST DUAL-SLOT PC CARD POWER SWITCH FOR SERIAL PCMCIA CONTROLLERS
The TPS2214A and TPS2216A PC Card power-interface switches provide an integrated power-management solution for two PC Cards. All of the discrete power MOSFETs, a logic section, current limiting, and thermal protection for PC Card control are combined on single integrated circuits. These low-cost devices allow the distribution of 3.3-V, 5-V, and/or 12-V power to the card. The current-limiting feature eliminates the need for fuses. Current-limit reporting can help the user isolate a system fault.
The TPS2214A and TPS2216A feature a 3.3-V low-voltage mode that allows for 3.3-V switching without the need for 5-V power. This feature facilitates low-power system designs such as sleep modes where only 3.3 V is available. These devices also have the ability to program the xVPP outputs independent of the xVCC outputs. A standby mode that changes all output-current limits to 50 mA typical has been incorporated.
End-equipment applications for these products include: notebook computers, desktop computers, personal digital assistants PDAs, digital cameras, and bar-code scanners.
The TPS2216A is backward-compatible with the TPS2202A, TPS2206, and TPS2216. The TPS2214A is backward-compatible with the TPS2214.
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS2214ADB TI 德州仪器 | 当前型号 | 当前型号 |
TPS2214DB 德州仪器 | 完全替代 | TPS2214ADB和TPS2214DB的区别 |
TPS2214DBG4 德州仪器 | 完全替代 | TPS2214ADB和TPS2214DBG4的区别 |
TPS2223DBRG4 德州仪器 | 完全替代 | TPS2214ADB和TPS2223DBRG4的区别 |
