高保真耳机放大器 HIGH FIDELITY HEADPHONE AMPLIFIER
This class D amplifier manufactured from Texas Instruments will strengthen your audio sound. This audio amplifier can handle a current up to 1400Typ mA. Its maximum power dissipation is 2800 mW. It has a differential input signal and a single output signal. It has a maximum load resistance of 64 Ohm. Its typical dual supply voltage is ±9|±12 V, with a minimum of ±5 V and maximum of ±15 V. It has a 2-channel stereo output. This audio amplifier has a minimum operating temperature of -40 °C and a maximum of 85 °C. Its typical PSRR is 75 dB. This device uses one or two power supplies.
电源电压DC 30.0 V
供电电流 26 mA
通道数 2
耗散功率 2.8 W
共模抑制比 100 dB
输出功率 80 mW
输入补偿电压 5 mV
输出电流Max 1400 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 2800 mW
共模抑制比Min 100 dB
电源电压Max 30 V
电源电压Min 10 V
安装方式 Surface Mount
引脚数 20
封装 SOIC-20
宽度 7.52 mm
封装 SOIC-20
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
香港进出口证 NLR
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TPA6120A2DWPR TI 德州仪器 | 当前型号 | 当前型号 |
TPA6120A2DWP 德州仪器 | 类似代替 | TPA6120A2DWPR和TPA6120A2DWP的区别 |
TPA6120A2DWPG4 德州仪器 | 类似代替 | TPA6120A2DWPR和TPA6120A2DWPG4的区别 |
TPA6120A2DWPRG4 德州仪器 | 功能相似 | TPA6120A2DWPR和TPA6120A2DWPRG4的区别 |
