MPU 监控和重置电路,Texas Instruments,0.8V 至 2.99VTexas Instruments 微处理器电源电压监控和重置电路系列,具有固定阈值电压电平。### 微处理器电源电压监控和复位电路电源电压监测和监控电路,用于台式机、便携式计算机和笔记本电脑、测试和测量仪器、便携式电池供电设备和多输出电源。电源电压探测器 电源电压监控器 电源监控器 微处理器监控 微处理器电压监控器 微控制器复位电路
MPU 监控和重置电路,Texas Instruments,0.8V 至 2.99V
Texas Instruments 微处理器电源电压监控和重置电路系列,具有固定阈值电压电平。
### 微处理器电源电压监控和复位电路
电源电压监测和监控电路,用于台式机、便携式计算机和笔记本电脑、测试和测量仪器、便携式电池供电设备和多输出电源。
电源电压探测器
电源电压监控器
电源监控器
微处理器监控
微处理器电压监控器
微控制器复位电路
得捷:
IC SUPERVISOR 1 CHANNEL 6WSON
立创商城:
TPS3838K33DRVT
德州仪器TI:
Active-low, open-drain, nano-power supervisors with manual reset
欧时:
Texas Instruments TPS3838K33DRVT 处理器监控器, 1.6 至 6 V监控电压, 多种输出驱动, 复位功能, 6引脚
贸泽:
监控电路 220nA Super
艾睿:
Do your circuit&s;s needs demand a great deal from your processor? The TPS3838K33DRVT microprocessor supervisory circuit from Texas Instruments is the perfect backup solution. This device has a maximum power dissipation of 1540 mW. Its typical operating supply voltage is 3.3 V. Its maximum power dissipation is 1540 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device has a typical operating supply voltage of 3.3 V. Its minimum operating supply voltage of 1.6 V, while its maximum is 6 V. It has a typical reset threshold voltage of 2.93 V, with a minimum of 2.84 V and a maximum of 2.99 V. This part has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
Processor Supervisor 2.93V 1.6V to 6V 6-Pin WSON EP T/R
Chip1Stop:
Processor Supervisor 2.93V 1.6V to 6V 6-Pin WSON EP T/R
Verical:
Processor Supervisor 2.93V 1 Active Low/Open Drain 6-Pin WSON EP T/R
Newark:
# TEXAS INSTRUMENTS TPS3838K33DRVT Supervisory Circuit, 1 Monitor, 1.6V-6V supply, 2.93V Threshold, 200 ms Delay, Active-Low Reset
DeviceMart:
IC 2.93V NANOPWR MON 6-SON
电源电压DC 1.60V min
供电电流 0.015 mA
耗散功率 1540 mW
静态电流 220 nA
阈值电压 2.93 V
复位电压Min 2.84 V
复位电压Max 2.99 V
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 1540 mW
电源电压Max 6 V
电源电压Min 1.6 V
安装方式 Surface Mount
引脚数 6
封装 WSON-6
长度 2 mm
宽度 2 mm
高度 0.75 mm
封装 WSON-6
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS3838K33DRVT TI 德州仪器 | 当前型号 | 当前型号 |
TPS3838K33DRVR 德州仪器 | 完全替代 | TPS3838K33DRVT和TPS3838K33DRVR的区别 |
TPS3838K33DRVRG4 德州仪器 | 功能相似 | TPS3838K33DRVT和TPS3838K33DRVRG4的区别 |
TPS3838K33DRVTG4 德州仪器 | 功能相似 | TPS3838K33DRVT和TPS3838K33DRVTG4的区别 |
